Measure Wind Speed Data Loggers & Turbine Kits
New WindTracker with anemometer
£267.00
-
This kit utilises the new WindTracker and wind speed sensor. This kit is the simplest yet effective way to accurately measure the potential of your site for a small wind turbine.
This kit brings all the key features from a professional wind monitoring system but at an entry level price. The kit comes with:
• new WindTracker• 1 x Vortex anemometer with 10m of sensor cable• Quick guide installation• Industrial grade batteries and industrial grade microSD card.If you need more technical specifications about the new WindTracker and sensors, just follow the links above. For generic F.A.Q, click here. -
Download quick installation guide here and for more information see F.A.Q. WindTracker and videos on how to use it.- Please note that there's a previous version of the WindTracker which we have limited stock only.
-
- WindTracker microSD card memory storage: Files in standard text format, archived into a single file. (Records total average wind speed, frequency distribution and wind rose)
- One anemometer and wind vane input: Measure wind speed and direction at the same time - Supports dry contact switch, hall effect switch or TTL level signal Wind direction input - Potentiometer type wind direction sensor - 16 bins wind direction (1 analogue input)
- Extremely Energy efficient: 2 x C type industrial grade alkaline batteries 1.5v - Up to 11 years of battery life (without memory card)
- Mechanical information: OTR: -40*C to + 70*C (check with us first for extreme weather applications)
- Sealed IP65 enclosure with cable gland for sensor wires
- Dimensions: 160x80x55mm
- Weight: 450gm including batteries
- Designed and assembled in Scotland
Download quick installation guide
Windlogger with anemometer
£357.00
- This kit is a guideline of typical setup for wind logging wind speed only (no wind direction) for small wind turbines where budget is very limited.
This kit brings all the key features from a professional wind monitoring system but at an entry level price. The kit comes with:• Vortex Anemometer with 10 meters of cable and attachment support for the mast• Quick guide installation• Industrial grade batteries and industrial grade microSD card.If you need more technical specifications about the new WindLogger and sensors, just follow the links above. For generic F.A.Q, click here. -
Download manual and quick guide here or see F.A.Q. for WindLogger and videos -
Specifications
- Record wind speeds from up to 2 anemometers simultaneously - Average wind speed, gust wind speed and standard deviation (turbulence) and wind direction
- Input for external temperature probe
- Up to 1 year of battery life recording 1 minute data or up to 3 years battery life recording in 10 minutes intervals. (10 seconds available for testing purposes)>- Time-stamped data recorded to microSD card in standard CSV format for import into Excel or wind analysis software. Includes all sensor values, plus battery status.- Simple analysis tools included. (excel template for your manipulation or Java app)
- Fully weatherproof IP65 rated enclosure
SD card memory storage
- Files in standard CSV ASCII format, archived into monthly files
- Records average, standard deviation and maximum values
- Data recorded with date and time stamp
- microSD flash card FAT32
Four sensor inputs
- Log two anemometers at once (2 digital inputs)- Supports dry contact (volt-free) switch, Hall effect switch, open collector or 3V logic level signal Wind speed input
- Potentiometer type wind direction sensor, 1k - 20k ohms.
- Support for external temperature sensor
Serial port to interface with PC
- RS232 compatible for reading values while logging data
- Setup menu via serial port or via SD card
- 4800bps
- Custom sensor factor setup via RS232Mechanical information
- Operating Temperature -40*C to + 70*C (check with us first for extreme weather applications)
- Sealed IP65 enclosure with gland for sensor wires
- Dimensions: 160x80x55mm
- Weight: 450gm including batteries
Download manual
WindTracker with anemometer & wind direction
£385.00
-
This wind kit will give you an accurate representation of the potential of your site for a small scale wind turbine. It includes one of the best wind speed and direction sensors (for its price!) you can buy today.
The new WindTracker wind speed and direction kit comes with all you need to start measuring accurately the potential of your new site. It does even come with the accessories to attach the anemometer to a pole. You will need to source your own small wind mast, we have seen amateur radio masts (10 and 15 meters) used for this and they work great. Alternatively, you can always use a scaffold pole (make sure you have proper cable guys in place)
You will receive with this kit:• new WindTracker• Pro-D Anemometer with 13 meters of cable and attachment support for the mast• Quick guide installation• Industrial grade batteries and Industrial grade microSD card.If you need more technical specifications about the new WindLogger and sensors, just follow the links above. For generic F.A.Q, click here. -
Download quick installation guide here and for more information see F.A.Q. WindTracker and videos on how to use it.
- Please note that there's a previous version of the WindTracker which we have limited stock only.
-
Specifications
- WindTracker microSD card memory storage: Files in standard text format, archived into a single file. (Records total average wind speed, frequency distribution and wind rose)
- One anemometer and wind vane input: Measure wind speed and direction at the same time - Supports dry contact switch, hall effect switch or TTL level signal Wind direction input - Potentiometer type wind direction sensor - 16 bins wind direction (1 analogue input)
- Extremely Energy efficient: 2 x C type industrial grade alkaline batteries 1.5v - Up to 11 years of battery life (without memory card)
- Mechanical information: OTR: -40*C to + 70*C (check with us first for extreme weather applications)
- Sealed IP65 enclosure with cable gland for sensor wires
- Dimensions: 160x80x55mm
- Weight: 450gm including batteries
- Designed and assembled in Scotland
Windlogger with anemometer & wind direction
£485.00
-
This kit is a guideline of typical setup for wind logging wind speed and wind direction for small wind turbines where budget is limited.
This kit brings all the key features from a professional wind monitoring system but at an entry level price. The kit comes with:• Pro-D Anemometer with 13 meters of cable and attachment support for the mast• Quick guide installation• Industrial grade batteries and Industrial grade microSD card.If you need more technical specifications about the new WindLogger and sensors, just follow the links above. For generic F.A.Q, click here. -
Download manual and quick guide here or see F.A.Q. for WindLogger and videos
-
Specifications
- Record wind speeds from up to 2 anemometers simultaneously - Average wind speed, gust wind speed and standard deviation (turbulence) and wind direction
- Input for external temperature probe
- Up to 1 year of battery life recording 1 minute data or up to 3 years battery life recording in 10 minutes intervals. (10 seconds available for testing purposes)>- Time-stamped data recorded to microSD card in standard CSV format for import into Excel or wind analysis software. Includes all sensor values, plus battery status.- Simple analysis tools included. (excel template for your manipulation or Java app)
- Fully weatherproof IP65 rated enclosure
SD card memory storage
- Files in standard CSV ASCII format, archived into monthly files
- Records average, standard deviation and maximum values
- Data recorded with date and time stamp
- microSD flash card FAT32
Four sensor inputs
- Log two anemometers at once (2 digital inputs)- Supports dry contact (volt-free) switch, Hall effect switch, open collector or 3V logic level signal Wind speed input
- Potentiometer type wind direction sensor, 1k - 20k ohms.
- Support for external temperature sensor
Serial port to interface with PC
- RS232 compatible for reading values while logging data
- Setup menu via serial port or via SD card
- 4800bps
- Custom sensor factor setup via RS232Mechanical information
- Operating Temperature -40*C to + 70*C (check with us first for extreme weather applications)
- Sealed IP65 enclosure with gland for sensor wires
- Dimensions: 160x80x55mm
- Weight: 450gm including batteries
WindLogger with 2 anemometers & wind vane
£573.00
-
This kit utilises the new WindLogger feature of having 2 anemometer inputs recording data simultaneously, so you can measure the wind speed at two different heights.
What is this good for? Mainly to calculate wind shear or more commonly used to extrapolate wind speed at a higher heights. Imagine you want to know the wind speed at 23 meters but your wind mast only reaches up to 18 meters. You could connect the top anemometer at 18 meters and the second one at 12 meters for example. With these two values you could extrapolate your wind speed at 23 meters without having to physically measure it. Just keep in mind it is not recommended to extrapolate more than 2/3rds of the top measurement point.
This kit brings all the key features from a professional wind monitoring system but at an entry level price. The kit comes with:
• new LeWL WindLogger• 1 x Combined anemometer with wind vane, with 13 meters of cable and attachment support for the mast• 1 x Vortex anemometer with 10m of sensor cable• Quick guide installation• Industrial grade batteries and industrial grade microSD card.If you need more technical specifications about the new WindLogger and sensors, just follow the links above. For generic F.A.Q, click here. -
Download manual and quick guide here or see F.A.Q. for WindLogger and videos
-
Specifications
- Record wind speeds from up to 2 anemometers simultaneously - Average wind speed, gust wind speed and standard deviation (turbulence) and wind direction
- Input for external temperature probe
- Up to 1 year of battery life recording 1 minute data or up to 3 years battery life recording in 10 minutes intervals. (10 seconds available for testing purposes)>- Time-stamped data recorded to microSD card in standard CSV format for import into Excel or wind analysis software. Includes all sensor values, plus battery status.- Simple analysis tools included. (excel template for your manipulation or Java app)
- Fully weatherproof IP65 rated enclosure
SD card memory storage
- Files in standard CSV ASCII format, archived into monthly files
- Records average, standard deviation and maximum values
- Data recorded with date and time stamp
- microSD flash card FAT32
Four sensor inputs
- Log two anemometers at once (2 digital inputs)- Supports dry contact (volt-free) switch, Hall effect switch, open collector or 3V logic level signal Wind speed input
- Potentiometer type wind direction sensor, 1k - 20k ohms.
- Support for external temperature sensor
Serial port to interface with PC
- RS232 compatible for reading values while logging data
- Setup menu via serial port or via SD card
- 4800bps
- Custom sensor factor setup via RS232Mechanical information
- Operating Temperature -40*C to + 70*C (check with us first for extreme weather applications)
- Sealed IP65 enclosure with gland for sensor wires
- Dimensions: 160x80x55mm
- Weight: 450gm including batteries
Temperature data logger
£169.00
This is a temperature data logger with extreme battery life, up to 3 years with with 10 minutes recording intervals.
It comes built-in with a uSD card that will store all your temperature readings every minute or 10 minutes onto a plan CSV text file.
The temperature range for the probe already installed is -30 to +60ºC (specifications of temperature sensor)
This temperature data logger comes with:
- IP66 tough enclosure
- +1 meter length pre-wired temperature probe
- Industrial grade micro SD card for data storage
- Industrial grade premium batteries
GSM 2G 3G Wind Data Logger with cloud storage
£495.00 £890.00
-
Overview
GSM & GPRS / 3G enabled 14 channel Datalogger used for live remote monitoring. Data is automatically sent every 10 minutes to the Logic Energy web portal, a fully automated and managed remote cloud application.
Connect your sensors, power up the system and that is all you need to start getting data. Set up takes typically less than 3 min
Benefits
• Fast data - GSM communications every 10 minutes
• Set your own alert functions
• Limit visits to site by monitoring battery, power supply, GSM and sensor status via remote web portal
• Save time with the special quick Wind report function already installed on Logic Energy web portal
• No software required on your computer to setup GSM data logger, just a web browser
• Robust and long lasting due to very low power consumption and good quality manufacturing in the Scotland
• Keep a track of your sites via Geo map location
Every GSM Wind data logger comes with
• Internet GSM 14 channel data logger & remote Logic Energy web portal access
• Sim with 1 year contract included
• AC Power supply
• GSM Antenna
• Free Shipping with this product
Download LeNETmobile GSM information
-
Specifications
Available channels: 14 channels - 4 digital anemometer, 2 x analogue wind vane, 4 digital counters, 4 analogue and power supply/battery monitor
Data Sampling rate: 1Hz (conforms to IEC 61400). Average, wind gust and standard deviation recorded and reported to Logic Energy web platform every 10 minute period
Resolution: 0.001Hz for wind speed and 0.3 degree for wind vane
Accuracy: Wind Speed (A1-A4) accuracy: better than 100ppm (parts per million). Analogue inputs accuracy better than 0.5%
Memory: Writes data to SD card every 10 minutes, capacity over 10 years.
Data Transfer: Automatic data transfer every 10 minutes to LeSENSE web portal
Antenna connector: SMA connector
Operating temperature: -20°c -70°c
Power consumption: Avg 5mA
Sensor Power: Pulsed 3.3Vdc, max 20mA total, 10 millisecond excitation pulse each sample period
Compatible sensors: Thies Clima, Vector Instruments, NRG, Secondwind, Davis and many more. Contact us if in doubt
Power Supply options: AC power or 12v rechargeable battery. Advanced PV power kit available including rechargeable battery, PV charger, PV panel and supporting bracket.
Software features: email Alert function, remove configuration of datalogger. Compatible with WINDCRANE iOS and Android App.
Data format: CSV, XLS, charts and raw data.
Material: Black High Gloss Acrylic Capped ABS
Dimensions: 160x125x13mm Weight: 303gm -
Features
Software Features
• Customisable dashboard
• Charting, reporting & Site comparison tools
• Data export tools in CSV, XLS or un-processed or raw format
• Geo Location map of all sites
• Remote GSM signal strength indicator
• Custom Alerts and logs function
• Online configuration of sensors
• Centralised data of all your systems & unlimited user access.
• Public live dashboards and mobile access
What will you remote monitor and log?
• Temperature sensor
• Humidity Sensor
• Power and Energy
• Voltage, Current & Energy
• Pressure
• Air Velocity
• Light, CO2, Occupancy
• And many more -
Videos
Connect and stream data to the Internet
Find devices using geo-location
Sensor data analysis online
Wind Speed Energy reports
Site comparison
You can find more video tutorials here - Reviews
